● The die-casting aluminium material use to the full lamp body, with a PMMA or PC transparent cover, and a high-purity alumina reflector which can effectively prevent glare.
● The rated power is 10 watts, which can provide a good decorative effect. The light source can be LED modules with high quality chips.
● The surface of the lamp is polished and pure polyester electrostatic spraying can effectively prevent corrosion. The entire lamp adopts stainless steel fasteners, which are not easy to corrode.
● Our product has obtained IP65 testing certificates, ISO and CE certificates.
● It can be used for decorative lighting of green belts in parks, garden villas, squares, and also widely used in urban slow lanes, narrow lanes, residential areas, tourist attractions, parks, squares, private gardens, courtyard corridors, lawns, and other public places, one or two volumes of roads are used for road lighting
Technical parameters: | |
Model No. |
CPD-1 |
Dimension(mm) |
Φ120MM*H580MM |
Material of Housing |
High pressure die-casting aluminum |
Material of Cover |
PMMA or PC |
Rated Power(W) |
10W |
Temperature of Color (W) |
2700-6500K |
Luminous Flux(W) |
100LM / W |
Input Voltage(v) |
AC85-265V |
Frequency range(HZ) |
50 / 60HZ |
Rendering Index of Color |
> 70 |
Working Ambient Temperature(℃) |
-40℃-60℃ |
Ambient humidity of Working |
10-90% |
LED Life(H) |
>50000H |
Packing Size(MM) |
250*130*600MM |
N.W(KGS) |
1.31 |
G.W(KGS) |
1.81 |
|
